Goldhofer

Popis

Colour : Blue payload weight : 110550 kg. Extendable Main Features Manufacturer: Goldhofer Type: THP / XLE 8 (3+5) Low Loader Chassis number: WG0THPX57B0030736 VIN Gooseneck: WG0SH0005B3030736 VIN XLE 3: WG0XLE034B0035242 VIN XLE 5: WG0THPX57B0030736 Year: 2012 Weights/Loading Capacity King-Pin load: 27.000 kg Axle load: 14.000 kg Total axle load: 8 x 14.000 kg = 112.000 kg GVW: 139.000 kg Empty weight: 28.450 kg Loading Capacity: 110.550 kg Axles BPW Pendle Axles Axle distance: 1360 mm / 1400 mm EBS/ABS Tyres: 285 / 70 R19.5 (150/148J) Hydraulic steering and suspension Radio remote control Dimensions Total length: 21.200 mm Loading floor length: 6.000 mm Loading floor extension: 8.500 mm Max loading floor length: 14.500 mm Loading floor thickness: 450 mm Loading floor clearance: 200 mm Loading floor width: 2.750 mm / 3.250 mm Bogie width: 2.750 mm Bogie height: 1.240 (+/- 300) Excavator boom recess: 700 mm Additional Information Hydraulic operated on truck PTO King pin 3,5” Central greasing Remote control operated Detachable gooseneck Hydraulic quick couplers Marker boards oversize loads Working lamps Orange warning light Ramps for loading on floor Extra tables for extanding loading floor
